LYH-300D UTM Machine Working And Construction ±1% Test Force Accuracy

Ask Lasest Price
Brand Name :	LIYI
Model Number :	LYH-300D
Certification :	CE ISO
Price :	Pending negotiation
Payment Terms :	L/C, D/A, T/T, Western Union
Supply Ability :	100 units per month
Delivery Time :	5-20days

Add to Cart

Product Details
Company Profile

LYH-300D UTM Machine Working And Construction ±1% Test Force Accuracy

LYH-300D UTM Machine Working And Construction ±1% Test Force Accuracy

Structure Introduction:

1. 1000KN Compression Tensile Testing Machine is mainly used to execute the tension, compression, bending, shearing etc. test for metal materials. Attached simple accessories and devices, it can be used to achieve many kinds of mechanical performances.

2. The oil cylinder is at the bottom of the load frame, tension space is at the upside of the load frame, compression and bending space is between lower crosshead and working table. The lower crosshead is driven by motor through decelerator, chain transmission device and screw pair, so realize the adjustment of testing space.

3. 1000KN Compression Tensile Testing Machine adopts Load cell measure load, use computer control & display load,

Main Parameters:

Tester Model		LYH-300D	LYH-600D	LYH-1000D	LYH-2000D
Max load(kN)		300	600	1000	2000
Test range		6KN-300kN	12KN-600kN	20KN-1000kN	40KN-2000kN
Test force accuracy		±1%
Displacement resolution		0.01mm
Deformation test accuracy		±0.5%
Constant force/ displacement controlling accuracy		SV<10%FS, less than ±1.0% of SV SV≥10%FS, less than ±0.5% of SV
Deformation rate control accuracy		Rate <0.05%FS, less than ±2.0% of SV Rate ≥0.05%FS, less than ±0.5% of SV
Max drawing space		800mm	800mm	850mm	800mm
Max compressing space		700mm	700mm	700mm	700mm
Flat sample clamp thickness		0-15mm	0-15mm	0-40mm	0-60mm
Round sample clamp diameter		φ6-φ26mm	φ13-φ40mm	φ13-φ60mm	φ15-φ70mm
Bending test branch space		450 mm
Branch width		140mm
Branch diameter		30mm
Piston Stroke		250mm
Clamp method		Built-in Hydraulic clamp
Outer demension	Machine	990×600×2435mm	990×600×2453mm	1100×770×2490mm	1160×1100× 2600mm
	Oil source	1100×700×950mm
Complete weight		2800kg	3000kg	4700kg	6500kg

Product Effects

LYH-300D UTM Machine Working And Construction ±1% Test Force Accuracy

Company Information

LIYI INTERNATIONAL is a professional manufacturer of various kinds of testing equipments over 12 years. LIYI products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and applicable to all scientific research units, quality inspection institutions and academic fields.

LYH-300D UTM Machine Working And Construction ±1% Test Force Accuracy

Our Services

If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation manual. We can provide video-con.

1. Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.

2.Excellent After sale Service:
12 months warranty. Besides, we can help you to repair your problem controller freely, even it's not from our factory. What you need to do is to send us the controller.

3.Commitment:
We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.

4.Good Packaging:

Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
