    Steel Column Universal Testing Machine 600 KN Electro - Hydraulic Servo motor

    Ask Lasest Price
    Brand Name : LIYI
    Model Number : WAW-600
    Certification : ISO
    Price : Negotiable
    Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 50 Pieces per Month
    Delivery Time : 15 days after receving deposit
    • Product Details
    • Company Profile

    Steel Column Universal Testing Machine 600 KN Electro - Hydraulic Servo motor


    600KN Electronic-Hydraulic Servo motor Steel Column Universal Testing Machine


    Introduction


    This machine, compared with a ball screw type electric mechanical UTM, is adopting oil hydraulic power to push the piston in the oil cylinder to provide loading force. Therefore it is very suitable for making test to different metal and nonmetal materials under high toughness and hardness against extreme big loading force. By using oil pressure transducer and photoelectric encoder, the computer is timely collecting the testing parameter like loading force, stroke etc. The servo system will provide on line close loop control and constant parameters control. The test software is able to create customized testing methods and setup testing report in only a few steps. WAW series is widely used in different inspection department, engineering area, universities and institutes.


    Main specifications


    Max. Test Force

    600KN

    Calibration accuracy class

    Class 1

    Column number

    4

    Force range

    20%-100% FS

    Force Accuracy

    Better than ±1% of reading

    Extension range

    1%-100% FS

    Extension accuracy

    Better than ±1% of reading

    Extension resolution

    1/350000 of max. extension

    Actuator (piston) speed

    0 ~ 100mm/min

    Clamping type

    Manual & automatic clamping

    Force loading speed

    0.02%-2%FS/s

    Constant stress control range

    2~60N/mm2·S-1

    Constant strain control range

    0.00025/s~0.0025/s

    Constant displacement control range

    0.5~50mm/min

    Column spacing (test space width)

    500mm

    Max. tension space

    600mm(customerized)

    Max. compression Space

    550mm

    Piston Stroke

    250mm

    Diameter of threaded steel

    Φ10 ~ φ40

    Tensile Fixture

    Round specimen fixture

    Ø13~Ø26mm Ø26~Ø40mm Ø40~Ø60mm

    Flat specimen fixture

    0~20mm 20~40mm

    Flat size

    200mm*200mm

    Bending adjust space

    600mm

    Deformation testing device

    Extensometer(customerized)

    Overall Dimension(L*W*H)

    900*650*2200mm

    Motor Power

    2.5KW

    Weight

    About 3500KG

    Power supply

    Three-phase 380V 50HZ


    Technical terms of Frame


    1. Lead screw driven cross head to adjust the test space
    2. Dual Zone Test Space.
    3. Automatic limit checking function.
    4. The system return automatically & the oil cylinder should return to the original position via manual or automatically after finishing testing.
    5. By the wedge action of hydraulic operated grips the specimen holding.
    6. High accuracy maintainable encoder.


    Photo Reference

    Steel Column Universal Testing Machine 600 KN Electro - Hydraulic Servo motorSteel Column Universal Testing Machine 600 KN Electro - Hydraulic Servo motor

    Steel Column Universal Testing Machine 600 KN Electro - Hydraulic Servo motor
